MMDFS6N303
MOSFET ELECTRICAL CHARACTERISTICS ? continued (T C = 25 ° C unless otherwise noted) (Note 7)
Characteristic
Symbol
Min
Typ
Max
Unit
SWITCHING CHARACTERISTICS (Note 8)
Turn ? On Delay Time
t d(on)
—
8.2
16.5
ns
Rise Time
Turn ? Off Delay Time
Fall Time
(V DD = 15 Vdc, I D = 1.0 Adc,
V GS = 10 Vdc,
R G = 6.0 Ω )
t r
t d(off)
t f
—
—
—
8.5
89.6
61.1
17
179
122
Gate Charge
(V DS = 15 Vdc, I D = 5.0 Adc,
V GS = 10 Vdc)
Q T
Q 1
Q 2
Q 3
—
—
—
—
15.7
2.0
4.6
3.9
31.4
—
—
—
nC
DRAIN SOURCE DIODE CHARACTERISTICS
Forward On ? Voltage (Note 7)
Reverse Recovery Time
Reverse Recovery Stored Charge
(I S = 1.7 Adc,
V GS = 0 Vdc)
(V GS = 0 V, I S = 5.0 A,
dIS/dt = 100 A/ m s)
V SD
t rr
t a
t b
Q RR
—
—
—
—
—
0.77
54.5
14.8
39.7
0.048
1.2
—
—
—
—
Vdc
ns
m C
SCHOTTKY RECTIFIER ELECTRICAL CHARACTERISTICS (T C = 25 ° C unless otherwise noted)
Maximum Instantaneous Forward Voltage (Note 7)
I F = 100 mAdc
I F = 3.0 Adc
I F = 6.0 Adc
Maximum Instantaneous Reverse Current (Note 7)
V R = 30 V
V F
I R
T J = 25 ° C
0.28
0.42
0.50
T J = 25 ° C
250
—
T J = 125 ° C
0.13
0.33
0.45
T J = 125 ° C
—
25
Volts
m A
mA
Maximum Voltage Rate of Change
V R = 30 V
dV/dt
10,000
V/ m s
7. Pulse Test: Pulse Width ≤ 300 m s, Duty Cycle ≤ 2.0%.
8. Switching characteristics are independent of operating junction temperature.
http://onsemi.com
3
